Neutrik NC3FD-LX-B - XLR Female Chassis Connector - Black Finish with Gold Contacts

The new DLX series features a compact all metal housing with an ingenious duplex ground contact, which offers excellent RF protection and shielding.

£4.16 £3.47
In Stock
Only 21 left
SKU
200-802

Neutrik NC3FD-LX-B - XLR Female Chassis Connector

  • 3 pole female chassis mount receptacle
  • Solder cups
  • Black metal housing
  • Gold contacts



Included in the Box

  • 1 x Neutrik NC3FD-LX-B - XLR Female Chassis Connector - Black Finish with Gold Contacts

Neutrik NC3FD-LX-B - XLR Female Chassis Connector

Neutrik's DLX series - the next generation of the popular DL XLR chassis connectors - provides unequalled performance through quality design. The new DLX series features a compact all metal housing with an ingenious duplex ground contact, which offers excellent RF protection and shielding. It is the ideal match for mating with Neutrik's EMC XLR cable connector. Reliability, robustness and dependability derive from incorporating latest components from the well proven and reliable XX and A series connectors.

  • Termination - Solder cups, now larger contacts for easier termination
  • Locking mechanism - Latch lock
  • Grounding - Separate duplex ground contact to mating connector shell and front panel with the option of solder connection to pin1 to chassis ground.
  • Suitable for both front and rear panel mount
  • Panel fastening - Standard: Countersunk mounting holes to accept M3 bolts or rivets
  • Panel thickness 1 - 3mm
  • All metal housing offers best overall RF protection and electromagnetic shielding
  • New duplex ground contact for excellent contact integrity between chassis and cable connector
  • Unique cage type female contact on 3 pole version increases conductivity and reduces wear on the mated male contact
  • Female contact incorporates a solder barrier to prevent solder running into the contact mating area
  • D-style housing provides installation compatibility with industry standard D mounting dimensions



More Information
Delivery Time In Stock
Price £3.47
Brand Neutrik
Manufacturer Code NC3FD-LX-B
Strapline The new DLX series features a compact all metal housing with an ingenious duplex ground contact, which offers excellent RF protection and shielding.
