NANLITE PavoSlim 60CL LED RGBWW Panel Light

NANLITE PavoSlim 60CL LED RGBWW Panel Light

The NANLITE Pavoslim 60CL is indispensable whether in small studios, low-ceiling locations or film and television sets with strict requirements.

The PavoSlim 60CL achieves four times the light output of similar sized / styled mat type LED lights. The NANLITE team has developed a dedicated optical system which maximizes output and heat dissipation to accomplish this. With its metal housing, the PavoSlim 60CL is both slim and rugged. Even when equipped with
a complete set of modifiers and accessories for installation, it is still lighter and thinner compared to traditional light mats.

The PavoSlim 60CL features a slim, elongated design measuring 2'×0.5' (602×152×18.6mm). The shape of the PavoSlim 60CL makes it especially well suited for in-vehicle, confined spaces and low ceiling shots. The useage range of the LED panel is enhanced by its super light weight, making it possible to mount practically anywhere, or handhold on-set for extended periods if required.

With RGBWW color mixing technology, PavoSlim 60CL provides HSI, RGBW, Gel and Effects modes. Importantly it also has a green/magenta (G/M) shift function for accurate matching with other light sources.

The PavoSlim 60CL operation is very straightforward. On the included control unit, all settings are accessed using just two buttons and two knobs, and are clearly displayed on the two-inch screen.

With built-in 2.4G and Bluetooth modules, the PavoSlim 60CL can be easily connected to the NANLINK APP.
This is a great way to achieve wireless intelligent lighting control, especially when integrated with other NANLITE tube lights and point source lights. Together they can create diverse and complementary lighting solutions.

Wired DMX allows for DMX/RDM control of the PavoSlim 60CL through a lighting desk.

The PavoSlim 60CL is equipped with LumenRadio CRMX, achieving wireless DMX/RDM control, ideal for using APPs like Blackout or hardware controllers like an Exalux or Gaffers Control.

The PavoSlim 60CL can be powered by AC power, V-mount batteries or NP-F batteries. All power supply methods support full power output. The PavoSlim 60CL also supports hot swapping amongst different power supply modes, allowing for continuous shooting without interruption.

Specifications

• Rated Power: 72W
• Input Voltage/Current: DC(Battery)14.4-26V
• DC(Battery)7.4V×2
• AC100-240V 50/60Hz
• CRI/TLCI: Average 96/Average 97
• CCT: 2700K-7500K (GM±150)
• Control: On-board control, 2.4G, Bluetooth, DMX/RDM, LumenRadio, NANLINK APP
• Product Size(mm): 602×152×18.6mm/23.70×5.98×0.73″
• Product Weight (kg): 0.98kg/2.16lb
• Illumination:
• 5600K: 22110 lux@0.5m, 7094 lux@1m, 1912 lux@2m
• 3200K: 18700 lux@0.5m, 6012 lux@1m, 1629 lux@2m
• R: 8280 lux@0.5m, 2432lux@1m,651 lux@2m
• G: 15080 lux@0.5m, 4445 lux@1m, 1143 lux@2m
• B: 2210 lux@0.5m, 660 lux@1m, 166 lux@2m
